One of the key elements of thermostatic water heaters to achieve instant constant temperature is the use of advanced heating technology, such as tankless water heaters or instant hot water systems. These systems heat water on demand, eliminating the need for a storage tank and ensuring hot water is always available when needed. By precisely controlling the heating process, these systems can provide water at a constant temperature and minimize fluctuations.
-Water temperature can be freely adjusted between 30 and 65°C
-Automatically establishes continuous stability, providing ease of use and comfort.
-The power can be automatically controlled and the temperature adjustment range is large.
-There is sufficient water and the water heater is working properly.
-The pressure of the gas and the temperature of the water are constant.
-Only a small amount of water at low pressure is required to turn it on.
-Water measurement function.
-Multiple protection functions, including no-load prevention of heating and shutdown
-Automatic pressure relief when power outage occurs, automatic pressure relief when pressure is extremely high
-Automatic shutdown due to overheating of water and combustion chamber, etc., making the device safe and reliable.
-The screen displays fault codes and has an alarm function.
-Can be placed in the bathroom.
1. Sensor switch: Using sensor switch design, it is convenient for users to operate and improves the user experience.
2. Anti-leakage protection:Equipped with an effective anti-leakage protection system to ensure safe use by users.
3. Continuous hot water supply:Continuously provide hot water to meet the user's continuous use needs, so you don't have to worry about interruptions in hot water supply.
4. Easy to install:The design is simple and easy to understand, and the installation process is simple and fast, saving time and effort.
5. Clear brightness of the panel: The panel adopts a high-definition display screen, which is clear and easy to read, making it more convenient for users to operate.
6. IPX4 waterproof:It has IPX4 waterproof performance, which can resist a certain degree of water splash and water mist, ensuring the stable operation of the product in humid environments.
Product |
Digital domestic gas hot water heating system |
|||
Installation |
Wall Mounted |
|||
Operation |
Mounted in kitchen, bathroom, etc. |
|||
Exhaust Way |
Force Exhaust Type |
|||
Capacity |
10-20L |
|||
Controller |
Digital Control |
|||
Temperature Range |
35℃ - 65℃ |
|||
Color |
Black / White / Silver |
|||
Heat Exchanger |
1.5-3.0KG Real Copper |
|||
Ignition Model |
Automatic elecrical pulse ignition 220V AC |
|||
Heat Efficiency |
≥85% |
|||
Use Gas Type |
LPG / NG |
|||
Rated Gas Pressure |
LPG:2800pa NG:1300pa OR 2000pa |
|||
Rated Voltage |
220V/50HZ & 110V/60HZ |
|||
Electric Power |
45W |
|||
Electrical Protection |
IPX4 |
|||
Noise Level |
70 dB(A) |
|||
Connection Pipe Spec |
Water Inlet: G1/2 |
|||
Water Outlet: G1/2 |
||||
Gas Inlet: G1/2 |
||||
Rate Heat Input Power |
20KW |
24KW |
28KW |
30KW |
Max Flow Rate (rise 25℃) |
10L/Min |
12L/Min |
14L/Min |
16L/Min |
Max Flow Rate (rise 20℃) |
12L/Min |
15L/Min |
18L/Min |
20L/Min |
Flue Duct Diameter |
Φ100(external), Φ60(internal) |
